1YNP

aldo-keto reductase AKR11C1 from Bacillus halodurans (apo form)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.25 Å
  • R-Value Free: 0.206
  • R-Value Work: 0.170
  • R-Value Observed: 0.172

wwPDB Validation   3D Report Full Report


This is version 2.1 of the entry. See complete history


Literature

High-resolution Crystal Structure of AKR11C1 from Bacillus halodurans: An NADPH-dependent 4-Hydroxy-2,3-trans-nonenal Reductase

Marquardt, T.Kostrewa, D.Balakrishnan, R.Gasperina, A.Kambach, C.Podjarny, A.Winkler, F.K.Balendiran, G.K.Li, X.D.

(2005) J Mol Biol 354: 304-316

  • DOI: https://doi.org/10.1016/j.jmb.2005.09.067
  • Primary Citation of Related Structures:
    1YNP, 1YNQ

  • PubMed Abstract:

    Aldo-keto reductase AKR11C1 from Bacillus halodurans, a new member of aldo-keto reductase (AKR) family 11, has been characterized structurally and biochemically. The structures of the apo and NADPH bound form of AKR11C1 have been solved to 1.25 A and 1.3 A resolution, respectively. AKR11C1 possesses a novel non-aromatic stacking interaction of an arginine residue with the cofactor, which may favor release of the oxidized cofactor. Our biochemical studies have revealed an NADPH-dependent activity of AKR11C1 with 4-hydroxy-2,3-trans-nonenal (HNE). HNE is a cytotoxic lipid peroxidation product, and detoxification in alkaliphilic bacteria, such as B.halodurans, plays a crucial role in survival. AKR11C1 could thus be part of the detoxification system, which ensures the well being of the microorganism. The very poor activity of AKR11C1 on standard, small substrates such as benzaldehyde or DL-glyeraldehyde is consistent with the observed, very open active site lacking a binding pocket for these substrates. In contrast, modeling of HNE with its aldehyde function suitably positioned in the active site suggests that its elongated hydrophobic tail occupies a groove defined by hydrophobic side-chains. Multiple sequence alignment of AKR11C1 with the highly homologous iolS and YqkF proteins shows a high level of conservation in this putative substrate-binding site. We suggest that AKR11C1 is the first structurally characterized member of a new class of AKRs with specificity for substrates with long aliphatic tails.


  • Organizational Affiliation

    Biomolecular Research, Paul Scherrer Institut, 5232 Villigen, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
oxidoreductase
A, B
317Halalkalibacterium halodurans C-125Mutation(s): 0
Gene Names: BH1011
UniProt
Find proteins for Q9KE47 (Halalkalibacterium halodurans (strain ATCC BAA-125 / DSM 18197 / FERM 7344 / JCM 9153 / C-125))
Explore Q9KE47
Go to UniProtKB:  Q9KE47
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9KE47
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-fructofuranose-(2-1)-alpha-D-glucopyranose
C
2N/A
Glycosylation Resources
GlyTouCan:  G05551OP
GlyCosmos:  G05551OP
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
E [auth A]
F [auth A]
G [auth A]
H [auth A]
I [auth A]
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
N [auth B],
O [auth B],
P [auth B],
Q [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
M [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
NA
Query on NA

Download Ideal Coordinates CCD File
D [auth A]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Biologically Interesting Molecules (External Reference) 1 Unique
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.25 Å
  • R-Value Free: 0.206
  • R-Value Work: 0.170
  • R-Value Observed: 0.172
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.669α = 90
b = 86.566β = 90
c = 105.427γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
MAR345data collection
XDSdata scaling
SHARPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-12-06
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Source and taxonomy, Version format compliance
  • Version 1.3: 2017-10-11
    Changes: Refinement description
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Database references, Derived calculations, Non-polymer description, Structure summary
  • Version 2.1: 2024-03-13
    Changes: Data collection, Database references, Structure summary
