4EXA

Crystal structure of the PA4992, the putative aldo-keto reductase from Pseudomona aeruginosa


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.272
  • R-Value Work: 0.227
  • R-Value Observed: 0.229

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

The AEROPATH project targeting Pseudomonas aeruginosa: crystallographic studies for assessment of potential targets in early-stage drug discovery.

Moynie, L.Schnell, R.McMahon, S.A.Sandalova, T.Boulkerou, W.A.Schmidberger, J.W.Alphey, M.Cukier, C.Duthie, F.Kopec, J.Liu, H.Jacewicz, A.Hunter, W.N.Naismith, J.H.Schneider, G.

(2013) Acta Crystallogr Sect F Struct Biol Cryst Commun 69: 25-34

  • DOI: https://doi.org/10.1107/S1744309112044739
  • Primary Citation of Related Structures:
    2XU8, 4AVF, 4AVR, 4AVY, 4B79, 4B7C, 4B7X, 4B9A, 4B9E, 4ES6, 4ETR, 4EXA, 4EXB

  • PubMed Abstract:

    Bacterial infections are increasingly difficult to treat owing to the spread of antibiotic resistance. A major concern is Gram-negative bacteria, for which the discovery of new antimicrobial drugs has been particularly scarce. In an effort to accelerate early steps in drug discovery, the EU-funded AEROPATH project aims to identify novel targets in the opportunistic pathogen Pseudomonas aeruginosa by applying a multidisciplinary approach encompassing target validation, structural characterization, assay development and hit identification from small-molecule libraries. Here, the strategies used for target selection are described and progress in protein production and structure analysis is reported. Of the 102 selected targets, 84 could be produced in soluble form and the de novo structures of 39 proteins have been determined. The crystal structures of eight of these targets, ranging from hypothetical unknown proteins to metabolic enzymes from different functional classes (PA1645, PA1648, PA2169, PA3770, PA4098, PA4485, PA4992 and PA5259), are reported here. The structural information is expected to provide a firm basis for the improvement of hit compounds identified from fragment-based and high-throughput screening campaigns.


  • Organizational Affiliation

    Biomedical Sciences Research Complex, University of St Andrews, St Andrews KY16 9ST, Scotland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Putative uncharacterized protein
A, B, C, D, E
A, B, C, D, E, F
292Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: PA4992
UniProt
Find proteins for Q9HUH3 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9HUH3
Go to UniProtKB:  Q9HUH3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9HUH3
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAP
Query on NAP

Download Ideal Coordinates CCD File
G [auth A]
H [auth B]
J [auth C]
L [auth D]
M [auth E]
G [auth A],
H [auth B],
J [auth C],
L [auth D],
M [auth E],
N [auth F]
NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H28 N7 O17 P3
XJLXINKUBYWONI-NNYOXOHSSA-N
EPE
Query on EPE

Download Ideal Coordinates CCD File
I [auth B],
K [auth C]
4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID
C8 H18 N2 O4 S
JKMHFZQWWAIEOD-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.272
  • R-Value Work: 0.227
  • R-Value Observed: 0.229
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 94.17α = 90
b = 120.277β = 90
c = 151.113γ = 90
Software Package:
Software NamePurpose
MxCuBEdata collection
PHASERphasing
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-01-09
    Type: Initial release
  • Version 1.1: 2013-01-16
    Changes: Database references
  • Version 1.2: 2018-01-24
    Changes: Structure summary
  • Version 1.3: 2019-03-20
    Changes: Data collection
  • Version 1.4: 2023-09-13
    Changes: Data collection, Database references, Derived calculations, Refinement description
