4WX6

Crystal structure of human adenovirus 8 protease with an irreversible vinyl sulfone inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.210
  • R-Value Observed: 0.214

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Structure-based design and optimization of potent inhibitors of the adenoviral protease.

Grosche, P.Sirockin, F.Mac Sweeney, A.Ramage, P.Erbel, P.Melkko, S.Bernardi, A.Hughes, N.Ellis, D.Combrink, K.D.Jarousse, N.Altmann, E.

(2015) Bioorg Med Chem Lett 25: 438-443

  • DOI: https://doi.org/10.1016/j.bmcl.2014.12.057
  • Primary Citation of Related Structures:
    4WX4, 4WX6, 4WX7

  • PubMed Abstract:

    Adenoviral infections are associated with a wide range of acute diseases, among which ocular viral conjunctivitis (EKC) and disseminated disease in immunocompromised patients. To date, no approved specific anti-adenoviral drug is available, but there is a growing need for an effective treatment of such infections. The adenoviral protease, adenain, plays a crucial role for the viral lifecycle and thus represents an attractive therapeutic target. Structure-guided design with the objective to depeptidize tetrapeptide nitrile 1 led to the novel chemotype 2. Optimization of scaffold 2 resulted in picomolar adenain inhibitors 3a and 3b. In addition, a complementary series of irreversible vinyl sulfone containing inhibitors were rationally designed, prepared and evaluated against adenoviral protease. High resolution X-ray co-crystal structures of representatives of each series proves the successful design of these inhibitors and provides an excellent basis for future medicinal chemistry optimization of these compounds.


  • Organizational Affiliation

    Novartis Institute for Biomedical Research, Novartis Campus, CH-4002 Basel, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Protease
A, C
204Human adenovirus D8Mutation(s): 0
Gene Names: L3
EC: 3.4.22.39
UniProt
Find proteins for B9A5C1 (Human adenovirus D serotype 8)
Explore B9A5C1
Go to UniProtKB:  B9A5C1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB9A5C1
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
PVI
B, D
11Human adenovirus D8Mutation(s): 0
UniProt
Find proteins for B9A5F5 (Human adenovirus D serotype 8)
Explore B9A5F5
Go to UniProtKB:  B9A5F5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB9A5F5
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
3VK
Query on 3VK

Download Ideal Coordinates CCD File
E [auth A],
F [auth C]
N-[(2S)-2-(3,5-dichlorophenyl)-2-(ethylamino)acetyl]-3-methyl-L-valyl-N-[3-(methylsulfonyl)propyl]glycinamide
C22 H34 Cl2 N4 O5 S
ZSBXAULTZFUUMY-RBUKOAKNSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.210
  • R-Value Observed: 0.214
  • Space Group: P 32
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 41.733α = 90
b = 41.733β = 90
c = 193.552γ = 120
Software Package:
Software NamePurpose
XDSdata reduction
REFMACrefinement
PDB_EXTRACTdata extraction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2015-01-14
    Type: Initial release
  • Version 1.1: 2015-01-28
    Changes: Database references
  • Version 1.2: 2024-11-13
    Changes: Data collection, Database references, Refinement description, Structure summary
