7CL7 | pdb_00007cl7

Substrate-free structure of CYP154C2 from Streptomyces avermitilis in an open conformation

• PDB DOI: https://doi.org/10.2210/pdb7CL7/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Streptomyces avermitilis MA-4680 = NBRC 14893
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2020-07-20 Released: 2021-07-21
• Deposition Author(s): Xu, L.H., Fushinobu, S.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.95 Å
• R-Value Free:
  0.243 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.197 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.199 (Depositor)

Starting Model: experimental

Literature

Substrate-free structure of CYP154C2 in an open conformation

Xu, L.H., Fushinobu, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 46.1 kDa
• Atom Count: 3,383
• Modeled Residue Count: 398
• Deposited Residue Count: 420
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome P450 hydroxylase	A	420	Streptomyces avermitilis MA-4680 = NBRC 14893	Mutation(s): 0  Gene Names: cyp19, SAVERM_3882
UniProt
Find proteins for Q82GL5 (Streptomyces avermitilis (strain ATCC 31267 / DSM 46492 / JCM 5070 / NBRC 14893 / NCIMB 12804 / NRRL 8165 / MA-4680)) Explore Q82GL5  Go to UniProtKB:  Q82GL5

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
HEM	B [auth A]	PROTOPORPHYRIN IX CONTAINING FE C34 H32 Fe N4 O4 KABFMIBPWCXCRK-RGGAHWMASA-L
PEG	C [auth A], D [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.95 Å
• R-Value Free:  0.243 (Depositor), 0.240 (DCC)
• R-Value Work:  0.197 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.199 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.98	α = 90
b = 80.04	β = 90
c = 121.13	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
iMOSFLM	data reduction
SCALA	data scaling
MOLREP	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2021-07-21
Deposition Author(s): Xu, L.H., Fushinobu, S.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	81402810

Revision History

• Version 1.0: 2021-07-21
  Type: Initial release

• Version 2.0: 2023-09-20
  Type: Coordinate replacement
  Reason: Atoms with unrealistic or zero occupancies
  Changes: Atomic model, Data collection, Database references, Derived calculations, Non-polymer description, Refinement description, Source and taxonomy, Structure summary
• Version 2.1: 2023-11-29
  Changes: Refinement description
