7K12

ACMSD in complex with diflunisal

  • Classification: LYASE
  • Organism(s): Pseudomonas fluorescens
  • Expression System: Escherichia coli BL21(DE3)
  • Mutation(s): No

  • Deposited: 2020-09-07 Released: 2021-01-13
  • Deposition Author(s): Yang, Y., Liu, A.
  • Funding Organization(s): National Science Foundation (NSF, United States), National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.17 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.201
  • R-Value Observed: 0.202

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Diflunisal Derivatives as Modulators of ACMS Decarboxylase Targeting the Tryptophan-Kynurenine Pathway.

Yang, Y.Borel, T.de Azambuja, F.Johnson, D.Sorrentino, J.P.Udokwu, C.Davis, I.Liu, A.Altman, R.A.

(2021) J Med Chem 64: 797-811

  • DOI: https://doi.org/10.1021/acs.jmedchem.0c01762
  • Primary Citation of Related Structures:
    7K12, 7K13

  • PubMed Abstract:

    In the kynurenine pathway for tryptophan degradation, an unstable metabolic intermediate, α-amino-β-carboxymuconate-ε-semialdehyde (ACMS), can nonenzymatically cyclize to form quinolinic acid, the precursor for de novo biosynthesis of nicotinamide adenine dinucleotide (NAD + ). In a competing reaction, ACMS is decarboxylated by ACMS decarboxylase (ACMSD) for further metabolism and energy production. Therefore, the inhibition of ACMSD increases NAD + levels. In this study, an Food and Drug Administration (FDA)-approved drug, diflunisal, was found to competitively inhibit ACMSD. The complex structure of ACMSD with diflunisal revealed a previously unknown ligand-binding mode and was consistent with the results of inhibition assays, as well as a structure-activity relationship (SAR) study. Moreover, two synthesized diflunisal derivatives showed half-maximal inhibitory concentration (IC 50 ) values 1 order of magnitude better than diflunisal at 1.32 ± 0.07 μM ( 22 ) and 3.10 ± 0.11 μM ( 20 ), respectively. The results suggest that diflunisal derivatives have the potential to modulate NAD + levels. The ligand-binding mode revealed here provides a new direction for developing inhibitors of ACMSD.


  • Organizational Affiliation

    Department of Chemistry, University of Texas at San Antonio, San Antonio, Texas 78249, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
2-amino-3-carboxymuconate 6-semialdehyde decarboxylase
A, B
355Pseudomonas fluorescensMutation(s): 0
Gene Names: nbaD
EC: 4
UniProt
Find proteins for Q83V25 (Pseudomonas fluorescens)
Explore Q83V25
Go to UniProtKB:  Q83V25
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ83V25
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.17 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.201
  • R-Value Observed: 0.202
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.588α = 90
b = 93.588β = 90
c = 445.743γ = 120
Software Package:
Software NamePurpose
DENZOdata reduction
HKL-2000data scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation (NSF, United States)United StatesCHE-1623856
National Science Foundation (NSF, United States)United StatesCHE-1808637
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM108988
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM133721
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesMH107985

Revision History  (Full details and data files)

  • Version 1.0: 2021-01-13
    Type: Initial release
  • Version 1.1: 2021-01-27
    Changes: Database references
  • Version 1.2: 2023-10-18
    Changes: Data collection, Database references, Refinement description
