Crystal structure of the Triticum xylanse inhibitor-I in complex with bacillus subtilis xylanase
Sansen, S., Dewilde, M., De Ranter, C.J., Gebruers, K., Brijs, K., Courtin, C.M., Delcour, J.A., Rabijns, A.To be published.
Experimental Data Snapshot
wwPDB Validation 3D Report Full Report
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
Endo-1,4-beta-xylanase A | A [auth X] | 185 | Bacillus subtilis | Mutation(s): 2 Gene Names: xynA EC: 3.2.1.8 | ![]() |
UniProt | |||||
Find proteins for P18429 (Bacillus subtilis (strain 168)) Explore P18429 Go to UniProtKB: P18429 | |||||
Entity Groups | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | P18429 | ||||
Sequence AnnotationsExpand | |||||
|
Entity ID: 2 | |||||
---|---|---|---|---|---|
ID | Chains | Name | Type/Class | 2D Diagram | 3D Interactions |
PRD_900116 Query on PRD_900116 | B [auth A] | 4beta-beta-xylobiose | Oligosaccharide / Metabolism |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 60.653 | α = 90 |
b = 60.653 | β = 90 |
c = 95.513 | γ = 120 |
Software Name | Purpose |
---|---|
REFMAC | refinement |
SCALA | data scaling |
CNS | refinement |
MOSFLM | data reduction |
CCP4 | data scaling |
CNS | phasing |
