3M5O

Crystal structure of HCV NS3/4A protease in complex with N-terminal product 5A5B


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.226
  • R-Value Work: 0.180
  • R-Value Observed: 0.182

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Drug resistance against HCV NS3/4A inhibitors is defined by the balance of substrate recognition versus inhibitor binding.

Romano, K.P.Ali, A.Royer, W.E.Schiffer, C.A.

(2010) Proc Natl Acad Sci U S A 107: 20986-20991

  • DOI: https://doi.org/10.1073/pnas.1006370107
  • Primary Citation of Related Structures:
    3M5L, 3M5M, 3M5N, 3M5O

  • PubMed Abstract:

    Hepatitis C virus infects an estimated 180 million people worldwide, prompting enormous efforts to develop inhibitors targeting the essential NS3/4A protease. Resistance against the most promising protease inhibitors, telaprevir, boceprevir, and ITMN-191, has emerged in clinical trials. In this study, crystal structures of the NS3/4A protease domain reveal that viral substrates bind to the protease active site in a conserved manner defining a consensus volume, or substrate envelope. Mutations that confer the most severe resistance in the clinic occur where the inhibitors protrude from the substrate envelope, as these changes selectively weaken inhibitor binding without compromising the binding of substrates. These findings suggest a general model for predicting the susceptibility of protease inhibitors to resistance: drugs designed to fit within the substrate envelope will be less susceptible to resistance, as mutations affecting inhibitor binding would simultaneously interfere with the recognition of viral substrates.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Pharmacology, University of Massachusetts Medical School, Worcester, MA 01605, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NS3/4A
A, B
203hepatitis C virus genotype 1aMutation(s): 19
Gene Names: NS3
EC: 3.4.21.98
UniProt
Find proteins for A8DG50 (hepatitis C virus genotype 1a)
Explore A8DG50
Go to UniProtKB:  A8DG50
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8DG50
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
TEDVVCC peptide
C, D
8hepatitis C virus genotype 1aMutation(s): 1
UniProt
Find proteins for B3TKQ3 (hepatitis C virus genotype 1a)
Explore B3TKQ3
Go to UniProtKB:  B3TKQ3
Entity Groups
UniProt GroupB3TKQ3
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.226
  • R-Value Work: 0.180
  • R-Value Observed: 0.182
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.272α = 90
b = 58.885β = 99.22
c = 67.058γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
PHASERphasing
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-11-24
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-08-09
    Changes: Advisory, Derived calculations, Refinement description, Source and taxonomy
