4C6D

Crystal structure of the dihydroorotase domain of human CAD bound to substrate at pH 6.0


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free: 0.134
  • R-Value Work: 0.121
  • R-Value Observed: 0.121

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.0 of the entry. See complete history


Literature

Structure, Functional Characterization and Evolution of the Dihydroorotase Domain of Human Cad.

Grande-Garcia, A.Lallous, N.Diaz-Tejada, C.Ramon-Maiques, S.

(2014) Structure 22: 185

  • DOI: https://doi.org/10.1016/j.str.2013.10.016
  • Primary Citation of Related Structures:
    4BY3, 4C6B, 4C6C, 4C6D, 4C6E, 4C6F, 4C6I, 4C6J, 4C6K, 4C6L, 4C6M, 4C6N, 4C6O, 4C6P, 4C6Q

  • PubMed Abstract:

    Upregulation of CAD, the multifunctional protein that initiates and controls the de novo biosynthesis of pyrimidines in animals, is essential for cell proliferation. Deciphering the architecture and functioning of CAD is of interest for its potential usage as an antitumoral target. However, there is no detailed structural information about CAD other than that it self-assembles into hexamers of ∼1.5 MDa. Here we report the crystal structure and functional characterization of the dihydroorotase domain of human CAD. Contradicting all assumptions, the structure reveals an active site enclosed by a flexible loop with two Zn²⁺ ions bridged by a carboxylated lysine and a third Zn coordinating a rare histidinate ion. Site-directed mutagenesis and functional assays prove the involvement of the Zn and flexible loop in catalysis. Comparison with homologous bacterial enzymes supports a reclassification of the DHOase family and provides strong evidence against current models of the architecture of CAD.


  • Organizational Affiliation

    Structural Bases of Genome Integrity Group, Structural Biology and Biocomputing Programme, Spanish National Cancer Research Centre (CNIO), 28029 Madrid, Spain.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CAD PROTEIN393Homo sapiensMutation(s): 0
EC: 6.3.4.16 (UniProt), 3.5.2.3 (UniProt), 6.3.5.5 (UniProt), 2.1.3.2 (UniProt), 3.5.1.2 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P27708 (Homo sapiens)
Explore P27708
Go to UniProtKB:  P27708
PHAROS:  P27708
GTEx:  ENSG00000084774
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP27708
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NCD
Query on NCD

Download Ideal Coordinates CCD File
C [auth A]N-CARBAMOYL-L-ASPARTATE
C5 H8 N2 O5
HLKXYZVTANABHZ-REOHCLBHSA-N
DOR
Query on DOR

Download Ideal Coordinates CCD File
B [auth A](4S)-2,6-DIOXOHEXAHYDROPYRIMIDINE-4-CARBOXYLIC ACID
C5 H6 N2 O4
UFIVEPVSAGBUSI-REOHCLBHSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
D [auth A],
E [auth A],
F [auth A],
H [auth A]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
FMT
Query on FMT

Download Ideal Coordinates CCD File
G [auth A],
I [auth A],
J [auth A],
K [auth A]
FORMIC ACID
C H2 O2
BDAGIHXWWSANSR-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
KCX
Query on KCX
A
L-PEPTIDE LINKINGC7 H14 N2 O4LYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free: 0.134
  • R-Value Work: 0.121
  • R-Value Observed: 0.121
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 82.08α = 90
b = 158.77β = 90
c = 61.56γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-02-05
    Type: Initial release
  • Version 1.1: 2014-02-19
    Changes: Database references
  • Version 2.0: 2023-12-20
    Changes: Atomic model, Data collection, Database references, Derived calculations, Other, Refinement description
