5EPO | pdb_00005epo

The three-dimensional structure of Clostridium absonum 7alpha-hydroxysteroid dehydrogenase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.222 (Depositor), 0.230 (DCC)
  • R-Value Work:
    0.182 (Depositor), 0.190 (DCC)
  • R-Value Observed:
    0.184 (Depositor)

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted NAPClick on this verticalbar to view detailsBest fitted TUDClick on this verticalbar to view details

This is version 1.2 of the entry. See complete history


Literature

The three-dimensional structure of Clostridium absonum 7 alpha-hydroxysteroid dehydrogenase: new insights into the conserved arginines for NADP(H) recognition

Lou, D.Wang, B.Tan, J.Zhu, L.Cen, X.Ji, Q.Wang, Y.

(2016) Sci Rep 6: 22885-22885

  • DOI: https://doi.org/10.1038/srep22885
  • Primary Citation of Related Structures:
    5EPO

  • PubMed Abstract:

    7α-hydroxysteroid dehydrogenase (7α-HSDH) can catalyse the oxidation of C7 α-OH of the steroid nucleus in the bile acid metabolism. In the paper we determined the crystal structure of 7α-HSDH from Clostridium absonum (CA 7α-HSDH) complexed with taurochenodeoxycholic acid (TCDCA) and NADP(+) by X-ray diffraction, which, as a tetramer, possesses the typical α/β folding pattern. The four subunits of an asymmetric unit lie in the fact that there are the stable hydrophobic interactions between Q-axis-related subunits. Significantly, we captured an active state of the NADP(+), confirming that nicotinamide moiety of NADP(+) act as electron carrier in the dehydrogenation. On the basis of crystal structure analysis, site-directed mutagenesis and MD simulation, furthermore, we find that the guanidinium of Arg38 can form the stable cation-π interaction with the adenine ring of NADP(+), and the cation-π interaction and hydrogen bonds between Arg38 and NADP(+) have a significant anchor effect on the cofactor binding to CA 7α-HSDH.


  • Organizational Affiliation

    Key Laboratory of Biorheological Science and Technology (Chongqing University), Ministry of Education, College of Bioengineering, Chongqing University, Chongqing 400030, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
7-alpha-hydroxysteroid deydrogenase
A, B, C, D
262Clostridium sardinienseMutation(s): 0
EC: 1.1.1
UniProt
Find proteins for G9FRD7 (Clostridium sardiniense)
Explore G9FRD7
Go to UniProtKB:  G9FRD7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG9FRD7
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NAP
Query on NAP

Download Ideal Coordinates CCD File
E [auth A],
H [auth B],
K [auth C],
N [auth D]
NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H28 N7 O17 P3
XJLXINKUBYWONI-NNYOXOHSSA-N
TUD
Query on TUD

Download Ideal Coordinates CCD File
F [auth A],
I [auth B],
L [auth C],
O [auth D]
TAUROCHENODEOXYCHOLIC ACID
C26 H45 N O6 S
BHTRKEVKTKCXOH-BJLOMENOSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
G [auth A],
J [auth B],
M [auth C],
P [auth D]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.222 (Depositor), 0.230 (DCC)
  • R-Value Work:  0.182 (Depositor), 0.190 (DCC)
  • R-Value Observed: 0.184 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 67.18α = 90
b = 69.68β = 90
c = 220.39γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted NAPClick on this verticalbar to view detailsBest fitted TUDClick on this verticalbar to view details

Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
China2014ZX09301306-007

Revision History  (Full details and data files)

  • Version 1.0: 2016-03-23
    Type: Initial release
  • Version 1.1: 2017-09-27
    Changes: Data collection, Derived calculations
  • Version 1.2: 2024-03-20
    Changes: Data collection, Database references
