6EPR | pdb_00006epr

The ATAD2 bromodomain in complex with compound UZH-DS15

• PDB DOI: https://doi.org/10.2210/pdb6EPR/pdb

• Classification: CYTOSOLIC PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2017-10-12 Released: 2018-10-31
• Deposition Author(s): Sledz, P., Caflisch, A.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.05 Å
• R-Value Free:
  0.232 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.196 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.198 (Depositor)

Literature

Hitting a moving target: simulation and crystallography study of ATAD2 bromodomain blockers

Sledz, P.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 16.04 kDa
• Atom Count: 1,194
• Modelled Residue Count: 130
• Deposited Residue Count: 130
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ATPase family AAA domain-containing protein 2	A	130	Homo sapiens	Mutation(s): 0  Gene Names: ATAD2, L16, PRO2000 EC: 3.6.1.3 (PDB Primary Data), 3.6.1 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q6PL18 (Homo sapiens) Explore Q6PL18  Go to UniProtKB:  Q6PL18
PHAROS:  Q6PL18 GTEx:  ENSG00000156802

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
BQE (Subject of Investigation/LOI)	B [auth A]	(~{N}~{Z},2~{R})-~{N}-[5-(5-azanylpyridin-3-yl)-4-ethanoyl-3~{H}-1,3-thiazol-2-ylidene]-1-[2-[4,4-bis(fluoranyl)cyclohexyl]ethyl]piperazine-2-carboxamide C23 H30 F2 N6 O2 S OVBCFTIQGNIZAI-GOSISDBHSA-N
SO4	C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.05 Å
• R-Value Free:  0.232 (Depositor), 0.240 (DCC)
• R-Value Work:  0.196 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.198 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 80.087	α = 90
b = 80.087	β = 90
c = 137.844	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-10-31
Deposition Author(s): Sledz, P., Caflisch, A.

Revision History

• Version 1.0: 2018-10-31
  Type: Initial release

• Version 1.1: 2019-11-13
  Changes: Data collection, Database references
• Version 1.2: 2024-05-08
  Changes: Data collection, Database references
