6NIN

Rhodobacter sphaeroides bc1 with STIGMATELLIN A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.60 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.249
  • R-Value Observed: 0.250

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.5 of the entry. See complete history


Literature

Crystal structure of bacterial cytochromebc1in complex with azoxystrobin reveals a conformational switch of the Rieske iron-sulfur protein subunit.

Esser, L.Zhou, F.Yu, C.A.Xia, D.

(2019) J Biol Chem 294: 12007-12019

  • DOI: https://doi.org/10.1074/jbc.RA119.008381
  • Primary Citation of Related Structures:
    6NHG, 6NHH, 6NIN

  • PubMed Abstract:

    Cytochrome bc 1 complexes (cyt bc 1 ), also known as complex III in mitochondria, are components of the cellular respiratory chain and of the photosynthetic apparatus of non-oxygenic photosynthetic bacteria. They catalyze electron transfer (ET) from ubiquinol to cytochrome c and concomitantly translocate protons across the membrane, contributing to the cross-membrane potential essential for a myriad of cellular activities. This ET-coupled proton translocation reaction requires a gating mechanism that ensures bifurcated electron flow. Here, we report the observation of the Rieske iron-sulfur protein (ISP) in a mobile state, as revealed by the crystal structure of cyt bc 1 from the photosynthetic bacterium Rhodobacter sphaeroides in complex with the fungicide azoxystrobin. Unlike cyt bc 1 inhibitors stigmatellin and famoxadone that immobilize the ISP, azoxystrobin causes the ISP-ED to separate from the cyt b subunit and to remain in a mobile state. Analysis of anomalous scattering signals from the iron-sulfur cluster of the ISP suggests the existence of a trajectory for electron delivery. This work supports and solidifies the hypothesis that the bimodal conformation switch of the ISP provides a gating mechanism for bifurcated ET, which is essential to the Q-cycle mechanism of cyt bc 1 function.


  • Organizational Affiliation

    Laboratory of Cell Biology, Center for Cancer Research, NCI, National Institutes of Health, Bethesda, Maryland 20892.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cytochrome b445Cereibacter sphaeroides 2.4.1Mutation(s): 1
Membrane Entity: Yes
UniProt
Find proteins for Q3IY10 (Cereibacter sphaeroides (strain ATCC 17023 / DSM 158 / JCM 6121 / CCUG 31486 / LMG 2827 / NBRC 12203 / NCIMB 8253 / ATH 2.4.1.))
Explore Q3IY10
Go to UniProtKB:  Q3IY10
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ3IY10
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Cytochrome c1272Cereibacter sphaeroides 2.4.1Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q3IY11 (Cereibacter sphaeroides (strain ATCC 17023 / DSM 158 / JCM 6121 / CCUG 31486 / LMG 2827 / NBRC 12203 / NCIMB 8253 / ATH 2.4.1.))
Explore Q3IY11
Go to UniProtKB:  Q3IY11
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ3IY11
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Ubiquinol-cytochrome c reductase iron-sulfur subunit187Cereibacter sphaeroides 2.4.1Mutation(s): 1
EC: 1.10.2.2 (PDB Primary Data), 7.1.1.8 (UniProt)
Membrane Entity: Yes
UniProt
Find proteins for Q3IY09 (Cereibacter sphaeroides (strain ATCC 17023 / DSM 158 / JCM 6121 / CCUG 31486 / LMG 2827 / NBRC 12203 / NCIMB 8253 / ATH 2.4.1.))
Explore Q3IY09
Go to UniProtKB:  Q3IY09
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ3IY09
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 7 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
HEC
Query on HEC

Download Ideal Coordinates CCD File
EA [auth F]
HB [auth X]
LA [auth L]
SA [auth P]
W [auth B]
EA [auth F],
HB [auth X],
LA [auth L],
SA [auth P],
W [auth B],
ZA [auth T]
HEME C
C34 H34 Fe N4 O4
HXQIYSLZKNYNMH-LJNAALQVSA-N
HEM
Query on HEM

Download Ideal Coordinates CCD File
AA [auth E]
BA [auth E]
DB [auth W]
EB [auth W]
IA [auth K]
AA [auth E],
BA [auth E],
DB [auth W],
EB [auth W],
IA [auth K],
JA [auth K],
PA [auth O],
QA [auth O],
S [auth A],
T [auth A],
WA [auth S],
XA [auth S]
PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
SMA
Query on SMA

Download Ideal Coordinates CCD File
CA [auth E]
FB [auth W]
KA [auth K]
RA [auth O]
U [auth A]
CA [auth E],
FB [auth W],
KA [auth K],
RA [auth O],
U [auth A],
YA [auth S]
STIGMATELLIN A
C30 H42 O7
UZHDGDDPOPDJGM-WPPYOTIYSA-N
6PE
Query on 6PE

Download Ideal Coordinates CCD File
DA [auth E],
GB [auth W],
V [auth A]
1,2-DIHEXANOYL-SN-GLYCERO-3-PHOSPHOETHANOLAMINE
C17 H33 N O8 P
PELYUHWUVHDSSU-OAHLLOKOSA-M
BOG
Query on BOG

Download Ideal Coordinates CCD File
BB [auth T]
FA [auth F]
JB [auth X]
NA [auth L]
TA [auth P]
BB [auth T],
FA [auth F],
JB [auth X],
NA [auth L],
TA [auth P],
Y [auth B]
octyl beta-D-glucopyranoside
C14 H28 O6
HEGSGKPQLMEBJL-RKQHYHRCSA-N
FES
Query on FES

Download Ideal Coordinates CCD File
CB [auth U]
HA [auth G]
KB [auth Y]
OA [auth M]
VA [auth Q]
CB [auth U],
HA [auth G],
KB [auth Y],
OA [auth M],
VA [auth Q],
Z [auth C]
FE2/S2 (INORGANIC) CLUSTER
Fe2 S2
NIXDOXVAJZFRNF-UHFFFAOYSA-N
SR
Query on SR

Download Ideal Coordinates CCD File
AB [auth T]
GA [auth F]
IB [auth X]
MA [auth L]
UA [auth P]
AB [auth T],
GA [auth F],
IB [auth X],
MA [auth L],
UA [auth P],
X [auth B]
STRONTIUM ION
Sr
PWYYWQHXAPXYMF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.60 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.249
  • R-Value Observed: 0.250
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 356.661α = 90
b = 145.752β = 104.97
c = 162.223γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-06-19
    Type: Initial release
  • Version 1.1: 2019-06-26
    Changes: Data collection, Database references
  • Version 1.2: 2019-08-21
    Changes: Data collection, Database references
  • Version 1.3: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Data collection, Derived calculations, Structure summary
  • Version 1.4: 2023-10-11
    Changes: Data collection, Database references, Refinement description, Structure summary
  • Version 1.5: 2024-10-23
    Changes: Structure summary
