7B97

CooS-V with oxidized hybrid cluster by hydroxylamine for 30 min


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.45 Å
  • R-Value Free: 0.171
  • R-Value Work: 0.134
  • R-Value Observed: 0.135

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

A Morphing [4Fe-3S-nO]-Cluster within a Carbon Monoxide Dehydrogenase Scaffold.

Jeoung, J.H.Fesseler, J.Domnik, L.Klemke, F.Sinnreich, M.Teutloff, C.Dobbek, H.

(2022) Angew Chem Int Ed Engl 61: e202117000-e202117000

  • DOI: https://doi.org/10.1002/anie.202117000
  • Primary Citation of Related Structures:
    7B7Q, 7B7T, 7B95, 7B97, 7B9A

  • PubMed Abstract:

    Ni,Fe-containing carbon monoxide dehydrogenases (CODHs) catalyze the reversible reduction of CO 2 to CO. Several anaerobic microorganisms encode multiple CODHs in their genome, of which some, despite being annotated as CODHs, lack a cysteine of the canonical binding motif for the active site Ni,Fe-cluster. Here, we report on the structure and reactivity of such a deviant enzyme, termed CooS-V Ch . Its structure reveals the typical CODH scaffold, but contains an iron-sulfur-oxo hybrid-cluster. Although closely related to true CODHs, CooS-V Ch catalyzes neither CO oxidation, nor CO 2 reduction. The active site of CooS-V Ch undergoes a redox-dependent restructuring between a reduced [4Fe-3S]-cluster and an oxidized [4Fe-2S-S*-2O-2(H 2 O)]-cluster. Hydroxylamine, a slow-turnover substrate of CooS-V Ch , oxidizes the hybrid-cluster in two structurally distinct steps. Overall, minor changes in CODHs are sufficient to accommodate a Fe/S/O-cluster in place of the Ni,Fe-heterocubane-cluster of CODHs.


  • Organizational Affiliation

    Humboldt-Universität zu Berlin, Institut für Biologie, Unter den Linden 6, 10099, Berlin, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Carbon monoxide dehydrogenase
A, B
629Carboxydothermus hydrogenoformans Z-2901Mutation(s): 0
Gene Names: cooSVCHY_0034
EC: 1.2.7.4
UniProt
Find proteins for Q3AG28 (Carboxydothermus hydrogenoformans (strain ATCC BAA-161 / DSM 6008 / Z-2901))
Explore Q3AG28
Go to UniProtKB:  Q3AG28
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ3AG28
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SF4 (Subject of Investigation/LOI)
Query on SF4

Download Ideal Coordinates CCD File
D [auth A],
I [auth B]
IRON/SULFUR CLUSTER
Fe4 S4
LJBDFODJNLIPKO-UHFFFAOYSA-N
T2N (Subject of Investigation/LOI)
Query on T2N

Download Ideal Coordinates CCD File
E [auth A],
J [auth B]
3,5-dioxa-7-thia-1-thionia-2$l^{2},4$l^{2},6$l^{3},8$l^{2}-tetraferrabicyclo[4.2.0]octane
Fe4 O2 S2
ZZXANUDJVNRRAL-UHFFFAOYSA-N
FES
Query on FES

Download Ideal Coordinates CCD File
C [auth A]FE2/S2 (INORGANIC) CLUSTER
Fe2 S2
NIXDOXVAJZFRNF-UHFFFAOYSA-N
BU3
Query on BU3

Download Ideal Coordinates CCD File
G [auth A],
H [auth A],
L [auth B],
M [auth B]
(R,R)-2,3-BUTANEDIOL
C4 H10 O2
OWBTYPJTUOEWEK-QWWZWVQMSA-N
H2S (Subject of Investigation/LOI)
Query on H2S

Download Ideal Coordinates CCD File
F [auth A],
K [auth B]
HYDROSULFURIC ACID
H2 S
RWSOTUBLDIXVET-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.45 Å
  • R-Value Free: 0.171
  • R-Value Work: 0.134
  • R-Value Observed: 0.135
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 65.196α = 90
b = 108.17β = 95.24
c = 82.232γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research Foundation (DFG)Germany390540038

Revision History  (Full details and data files)

  • Version 1.0: 2022-01-12
    Type: Initial release
  • Version 1.1: 2022-07-27
    Changes: Database references
  • Version 1.2: 2024-01-31
    Changes: Data collection, Refinement description
