9C3T | pdb_00009c3t

Crystal structure of DNA N6-Adenine Methyltransferase M.BceJIV from Burkholderia cenocepacia in complex with duplex DNA substrate containing GTAAAC as recognition sequence


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.37 Å
  • R-Value Free:
    0.235 (Depositor), 0.226 (DCC)
  • R-Value Work:
    0.181 (Depositor), 0.187 (DCC)
  • R-Value Observed:
    0.183 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted SFGClick on this verticalbar to view details

This is version 1.2 of the entry. See complete history


Literature

Burkholderia cenocepacia epigenetic regulator M.BceJIV simultaneously engages two DNA recognition sequences for methylation.

Quintana-Feliciano, R.Kottur, J.Ni, M.Ghosh, R.Salas-Estrada, L.Ahlsen, G.Rechkoblit, O.Shapiro, L.Filizola, M.Fang, G.Aggarwal, A.K.

(2024) Nat Commun 15: 7839-7839

  • DOI: https://doi.org/10.1038/s41467-024-52130-x
  • Primary Citation of Related Structures:
    8URK, 9C3S, 9C3T, 9C3U

  • PubMed Abstract:

    Burkholderia cenocepacia is an opportunistic and infective bacterium containing an orphan DNA methyltransferase called M.BceJIV with roles in regulating gene expression and motility of the bacterium. M.BceJIV recognizes a GTWWAC motif (where W can be an adenine or a thymine) and methylates N6 of the adenine at the fifth base position. Here, we present crystal structures of M.BceJIV/DNA/sinefungin ternary complex and allied biochemical, computational, and thermodynamic analyses. Remarkably, the structures show not one, but two DNA substrates bound to the M.BceJIV dimer, with each monomer contributing to the recognition of two recognition sequences. We also show that methylation at the two recognition sequences occurs independently, and that the GTWWAC motifs are enriched in intergenic regions in the genomes of B. cenocepacia strains. We further computationally assess the interactions underlying the affinities of different ligands (SAM, SAH, and sinefungin) for M.BceJIV, as a step towards developing selective inhibitors for limiting B. cenocepacia infection.


  • Organizational Affiliation

    Department of Pharmacological Sciences, Icahn School of Medicine at Mount Sinai, New York, New York, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Methyltransferase
A, B, C, D
283Burkholderia cenocepaciaMutation(s): 0
Gene Names: JAO13_04290
EC: 2.1.1
UniProt
Find proteins for B4EFK1 (Burkholderia cenocepacia (strain ATCC BAA-245 / DSM 16553 / LMG 16656 / NCTC 13227 / J2315 / CF5610))
Explore B4EFK1
Go to UniProtKB:  B4EFK1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB4EFK1
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.37 Å
  • R-Value Free:  0.235 (Depositor), 0.226 (DCC)
  • R-Value Work:  0.181 (Depositor), 0.187 (DCC)
  • R-Value Observed: 0.183 (Depositor)
Space Group: I 41
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 137.728α = 90
b = 137.728β = 90
c = 167.315γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted SFGClick on this verticalbar to view details

Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2024-09-11
    Type: Initial release
  • Version 1.1: 2024-09-18
    Changes: Database references
  • Version 1.2: 2024-09-25
    Changes: Database references
