9FZC

Structure of OmpA-short in complex with nanobody Nb01

PDB DOI: https://doi.org/10.2210/pdb9FZC/pdb

Classification: MEMBRANE PROTEIN
Organism(s): Escherichia coli K-12, Vicugna pacos
Expression System: Escherichia coli K-12
Mutation(s): No
Membrane Protein: Yes PDBTMMemProtMD

Deposited: 2024-07-05 Released: 2024-07-17
Deposition Author(s): Ackle, F., Sorgenfrei, M., Seeger, M.A.
Funding Organization(s): Swiss National Science Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.27 Å
R-Value Free: 0.234
R-Value Work: 0.208
R-Value Observed: 0.209

Starting Models: experimental, in silico
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Rapid detection and capture of clinical Escherichia coli strains mediated by OmpA-targeting nanobodies

Sorgenfrei, M., Hurlimann, L.M., Printz, A., Wegner, F., Morger, D., Ackle, F., Remy, M.M., Montowski, G., Keserue, H., Cuenod, A., Imkamp, F., Egli, A., Keller, P.M., Seeger, M.A.

To be published.

Macromolecule Content

Total Structure Weight: 66.92 kDa
Atom Count: 4,898
Modelled Residue Count: 578
Deposited Residue Count: 592
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Outer membrane protein A	A, B	173	Escherichia coli K-12	Mutation(s): 0 Gene Names: ompA, con, tolG, tut, b0957, JW0940 Membrane Entity: Yes
UniProt
Find proteins for P0A910 (Escherichia coli (strain K12)) Explore P0A910 Go to UniProtKB: P0A910
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0A910
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Nanobody 01	C, D	123	Vicugna pacos	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
OCT Query on OCT Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain U [auth B] SDF format, chain V [auth B] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B] mmCIF format, chain U [auth B] mmCIF format, chain V [auth B]	E [auth A] F [auth A] G [auth A] H [auth A] I [auth A] E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], L [auth B], M [auth B], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B], S [auth B], T [auth B], U [auth B], V [auth B]	N-OCTANE C₈ H₁₈ TVMXDCGIABBOFY-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B]
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain W [auth B] MOL2 format, chain K [auth A] MOL2 format, chain W [auth B] mmCIF format, chain K [auth A] mmCIF format, chain W [auth B]	K [auth A], W [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Focus chain W [auth B] Interactions & Density Focus chain K [auth A] Focus chain W [auth B]
